| Nomor Bagian | HSD121KXN1-B00-C10 |
| Merek | HannStar |
| Ukuran | 12.1 |
| Aplikasi | Automotive Display |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | HannStar |
| ukuran panel | 12.1" |
| resolusi | 1024(RGB)×768, XGA, 105PPI |
| area tampilan | 245.76(W)×184.32(H) mm |
| kecerahan | 600 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 72% NTSC |
| frekuensi | 60Hz |
| berat | - |
| model panel | HSD121KXN1-B00-C10 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| rasio kontras | 900:1 (Typ.) (TM) |
| mode tampilan | IPS Pro, Normally Black, Transmissive |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 30K hours , With LED Driver |
| layar sentuh | Embeded Touch |
| aplikasi | Automotive Display |
