| Nomor Bagian | HSD104KXN1-A10 |
| Merek | HannStar |
| Ukuran | 10.4 |
| Aplikasi | Automotive Display |
| Resolusi | 1024×768 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.2M |
| Lampu latar | 4S8P |
| Antarmuka | |
| pabrikan | HannStar |
| nama model | HSD104KXN1-A10 |
| ukuran layar | 10.4 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1024(RGB)×768 (XGA) 123PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 211.2 × 158.4 (H×V) |
| garis besar (mm) | 236 × 174.3 × 7 (H×V×D) |
| area bezel (mm) | 213.2 × 160.4 (H×V) |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 600 cd/m² (Typ.) |
| rasio kontras | 900 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS Pro, Normally Black, Transmissive |
| kedalaman warna | 262K/16.2M |
| lampu latar | 4S8P WLED , 30K hours , No Driver |
| massa | 316g |
| digunakan untuk | Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
