| Nomor Bagian | HSD088KPW1-A10 |
| Merek | HannStar |
| Ukuran | 8.8 |
| Aplikasi | Automotive Display |
| Resolusi | 1920×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| pabrikan | HannStar |
| ukuran layar | 8.8 inch |
| nomor piksel | 1920×480(RGB) 222PPI |
| area aktif (mm) | 218.88 × 54.72 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 600 (Typ.)(cd/m²) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M 50% NTSC |
| massa | 110g (Typ.) |
| tingkat penyegaran | 60Hz |
| nama model | HSD088KPW1-A10 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Horizontal Stripe |
| garis besar (mm) | 231.3 × 64.3 × 5.1 (H×V×D) |
| perlakuan | Hard coating |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| mode kerja | IPS Pro, Normally Black, Transmissive |
| tanggapan | 40 (Typ.)(Tr+Td) ms |
| lampu latar | WLED , 30K hours , No Driver |
| digunakan untuk | Automotive Display |
| layar sentuh | Without |
