| Nomor Bagian | HSD088IPW1-B00 |
| Merek | HannStar |
| Ukuran | 8.8 |
| Aplikasi | Automotive Display |
| Resolusi | 1920×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| pabrikan | HannStar |
| nama model | HSD088IPW1-B00 |
| ukuran layar | 8.8 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 1920×480(RGB) 222PPI |
| pengaturan | RGB Horizontal Stripe |
| area aktif (mm) | 218.88 × 54.72 (H×V) |
| garis besar (mm) | - |
| pencahayaan | - |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS Pro, Normally Black, Transmissive |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | WLED , 30K hours , No Driver |
| massa | - |
| digunakan untuk | Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | MIPI (4 data lanes) , 40 pins Connector |
| sumber tegangan | 3.3/12.0/20.0/-10.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| CLAA088WA01XN | CPT | 8.8 | 1280×480 |
| LQ088H9DR01U | SHARP | 8.8 | 640×240 |
| LQ088H9DZ03 | SHARP | 8.8 | 640×240 |
| LQ088Y3DG01 | SHARP | 8.8 | 800×480 |
| S088WX03 | CDTECH | 8.8 | 1280×320 |
| T-51965GD088ZU-MFW-AEN | Kyocera | 8.8 | 640×240 |
