| Nomor Bagian | HSD061IDW1-A00-R00 |
| Merek | HannStar |
| Ukuran | 6.1 |
| Aplikasi | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 6S2P |
| Antarmuka | Parallel |
| merek panel | HannStar |
| model panel | HSD061IDW1-A00-R00 |
| ukuran panel | 6.1" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 800(RGB)×480, WVGA, 153PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 132(W)×79.2(H) mm |
| bukaan bezel | 143.3(W)×81.6(H) mm |
| ukuran garis besar | 144.8(W)×87.6(H) ×4.8(D) mm |
| permukaan | Antiglare (Haze 8%), Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | 75/75/60/70 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 48% NTSC |
| jenis lampu | 6S2P WLED , 10K hours , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | 4-wire Resistive Touch |
| berat panel | 140g (Max.) |
| aplikasi | Automotive Display |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit) + SPI , 50 pins FPC |
| tegangan masukan | 1.8/3.3/3.3V (Typ.)(VDD1/VDD2/VCI) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| A061FW01 V0 | AUO | 6.1 | 480×234 |
| A061VW01 V0 | AUO | 6.1 | 800×480 |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| GCX142AKM-E | SONY | 6.1 | 800×480 |
| K6488L-FF | CITIZEN | 6.1 | 640×480 |
| LA061WQ1-TD04 | LG Display | 6.1 | 480×272 |
| LQ061Y1VG01 | SHARP | 6.1 | 800×480 |
| PM061WX1 | E Ink | 6.1 | 800×480 |
