| Nomor Bagian | H546DLK01.0 |
| Merek | AUO |
| Ukuran | 5.5 |
| Aplikasi | Mobile Phone |
| Resolusi | 1080×1920 |
| Komposisi | AM-OLED , OLED |
| Kecerahan | |
| CR | 10000:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antarmuka | MIPI |
| merek panel | AUO |
| ukuran panel | 5.5" |
| resolusi | 1080(RGB)×1920, FHD, 403PPI |
| area tampilan | 68.04(W)×120.96(H) mm |
| ukuran garis besar | 70.84(W)×128.01(H) ×0.92(D) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandang | 80/80/80/80 (Min.)(CR≥1600) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 100% NTSC |
| frekuensi | 100Hz |
| ic pengemudi | COG Built-in RM69071 |
| berat panel | - |
| antarmuka sinyal | MIPI (4 data lanes) |
| tegangan masukan | 1.8/3.1/5.8/4.6/-2.9V (Typ.)(IOVCC/VCI/AVDD/OVDD/OVSS) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | H546DLK01.0 |
| tipe panel | AM-OLED , OLED |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Hard coating (3H) |
| rasio kontras | 10000:1 (Min.) (TM) |
| mode tampilan | - |
| waktu merespon | - |
| jenis lampu | self |
| layar sentuh | Embeded Touch |
| aplikasi | Mobile Phone |
| H546DAN01.2 | AUO | 5.5 | 1080×1920 |
| H546DLB01.1 | AUO | 5.5 | 1080×1920 |
| LPM055A138A | JDI | 5.5 | 1440×2560 |
| LQ055T3SX02Z | SHARP | 5.5 | 1080×1920 |
| NL3224AC35-05 | NLT | 5.5 | 320×240 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| TM055JDHP71 | Tianma | 5.5 | 720×1280 |
