| Nomor Bagian | GV185FHM-N10-DM30 |
| Merek | BOE |
| Ukuran | 18.5 |
| Aplikasi | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 11S4P |
| Antarmuka | LVDS |
| merek panel | BOE |
| model panel | GV185FHM-N10-DM30 |
| ukuran panel | 18.5" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 119PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 408.96(W)×230.04(H) mm |
| bukaan bezel | 410.96(W)×232.04(H) mm |
| ukuran garis besar | 430.4(W)×254.6(H) ×12.5(D) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 70% NTSC |
| jenis lampu | 11S4P WLED , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 1.80Kgs (Typ.) |
| aplikasi | Industrial |
| antarmuka sinyal | LVDS (2 ch, 8-bit) , 30 pins Connector |
| tegangan masukan | 5.0V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
