| Nomor Bagian | GV122WXM-N80 |
| Merek | BOE |
| Ukuran | 12.2 |
| Aplikasi | Industrial |
| Resolusi | 1280×800 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | BOE |
| nama model | GV122WXM-N80 |
| ukuran layar | 12.2 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 1280(RGB)×800 (WXGA) 123PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 262.656 × 164.16 (H×V) |
| garis besar (mm) | 278 × 184 × 9.91 (H×V×D) |
| area bezel (mm) | 264.66 × 166.66 (H×V) |
| perlakuan | - |
| pencahayaan | 450 cd/m² (Typ.) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td); 45 (Typ.)(G to G) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | WLED , With LED Driver |
| massa | 564g (Typ.) |
| digunakan untuk | Industrial |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (1 ch, 8-bit) , 30 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
