| Nomor Bagian | G229HAN01.0 |
| Merek | AUO |
| Ukuran | 22.9 |
| Aplikasi | Industrial Stretched |
| Resolusi | 1920×165 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | AUO |
| ukuran panel | 22.9" |
| resolusi | 1920(RGB)×165, 84PPI |
| area tampilan | 578.88(W)×49.7475(H) mm |
| ukuran garis besar | 587.08(W)×62.05(H) ×10.71(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 72% NTSC |
| frekuensi | 60Hz |
| berat | 460g (Typ.) |
| model panel | G229HAN01.0 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 580.88(W)×51.75(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | AHVA, Normally Black, Transmissive |
| waktu merespon | 13/12 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 70K hours , With LED Driver |
| layar sentuh | Without |
| aplikasi | Industrial Stretched Bar LCD |
