| Nomor Bagian | G190EAN01.6 |
| Merek | AUO |
| Ukuran | 19.0 |
| Aplikasi | Industrial Medical I |
| Resolusi | 1280×1024 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AUO |
| model | G190EAN01.6 |
| ukuran diagonal | 19.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×1024 [SXGA] 86PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 376.32(H)×301.056(V) mm |
| garis besar redup. | 396(H)×324(V) ×15.8(D) mm |
| daerah bezel | 380.32(H)×305.06(V) mm |
| perlakuan | Antiglare |
| pencahayaan | 1000 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 13/12 (Typ.)(Tr/Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| Modus operasi | AHVA, Normally Black, Transmissive |
| warna pendukung | 16.7M 72% NTSC |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat | 1.70±0.15Kgs |
| dirancang untuk | Industrial Medical Imaging Outdoor High Brightness |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (2 ch, 8-bit) |
| Sumber Daya listrik | 5.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
