| Nomor Bagian | G170ETN03.1 |
| Merek | AUO |
| Ukuran | 17.0 |
| Aplikasi | Industrial |
| Resolusi | 1280×1024 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AUO |
| model | G170ETN03.1 |
| ukuran diagonal | 17.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×1024 [SXGA] 96PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 337.92(H)×270.336(V) mm |
| garis besar redup. | 358.5(H)×296.5(V) ×10.8(D) mm |
| daerah bezel | 341.7(H)×274.1(V) mm |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 400 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | - |
| waktu merespon | 3.8/1.2 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/80/80 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 16.7M 72% NTSC |
| sumber cahaya | WLED [9S4P] , 30K hours , W/O Driver |
| berat | 1.27Kgs (Typ.) |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Sumber Daya listrik | 5.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
