| Nomor Bagian | G156HAN02.1 |
| Merek | AUO |
| Ukuran | 15.6 |
| Aplikasi | Industrial Medical I |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | AUO |
| ukuran layar | 15.6 inch |
| nomor piksel | 1920(RGB)×1080 (FHD) 141PPI |
| area aktif (mm) | 344.16 × 193.59 (H×V) |
| area bezel (mm) | 347.06 × 196.49 (H×V) |
| pencahayaan | 500 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M 99% sRGB |
| massa | 600/660g (Typ./Max.) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | LVDS (2 ch, 8-bit) , 30 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
| nama model | G156HAN02.1 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 363.8 × 215.9 × 9.3 (H×V×D) |
| perlakuan | Antiglare, Hard coating (3H) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| tanggapan | 25 (Typ.)(Tr+Td) ms |
| mode kerja | AHVA, Normally Black, Transmissive |
| lampu latar | WLED , 50K hours , With LED Driver |
| digunakan untuk | Industrial Medical Imaging |
| layar sentuh | Without |
