| Nomor Bagian | G150XTN03.6 |
| Merek | AUO |
| Ukuran | 15.0 |
| Aplikasi | Industrial |
| Resolusi | 1024×768 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | AUO |
| ukuran layar | 15.0 inch |
| nomor piksel | 1024(RGB)×768 (XGA) 85PPI |
| area aktif (mm) | 304.128 × 228.096 (H×V) |
| area bezel (mm) | 313.55 × 237.25 (H×V) |
| pencahayaan | 250 cd/m² (Typ.) |
| sudut pandang | 45/45/20/40 (Typ.)(CR≥10) |
| pemandangan bagus di | - |
| kedalaman warna | 262K/16.2M 60% NTSC |
| massa | 1.10Kgs (Max.) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 65 °C |
| nama model | G150XTN03.6 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 326.5 × 253.5 × 10 (H×V×D) |
| perlakuan | Antiglare, Hard coating (3H) |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| tanggapan | 5.7/2.3 (Typ.)(Tr/Td) ms |
| mode kerja | TN, Normally White, Transmissive |
| lampu latar | WLED , 50K hours , With LED Driver |
| digunakan untuk | Industrial |
| layar sentuh | Without |
