| Nomor Bagian | G101STN01.D |
| Merek | AUO |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1024×600 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | AUO |
| ukuran layar | 10.1 inch |
| nomor piksel | 1024(RGB)×600 (WSVGA) 117PPI |
| area aktif (mm) | 222.72 × 125.28 (H×V) |
| area bezel (mm) | 226.43 × 128.1 (H×V) |
| pencahayaan | 450 cd/m² (Typ.) |
| sudut pandang | 70/70/60/60 (Typ.)(CR≥10) |
| pemandangan bagus di | - |
| kedalaman warna | 262K/16.7M 45% NTSC |
| massa | 180g (Typ.) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| nama model | G101STN01.D |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 235 × 143 × 5.2 (H×V×D) |
| perlakuan | Antiglare, Hard coating (3H) |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| tanggapan | 7/9 (Typ.)(Tr/Td) ms |
| mode kerja | TN, Normally White, Transmissive |
| lampu latar | WLED , 50K hours , With LED Driver |
| digunakan untuk | Industrial |
| layar sentuh | Without |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| B101AW01 V2 HW0A | AUO | 10.1 | 1024×576 |
| CLAA101ND07CW | CPT | 10.1 | 1024×600 |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| LP101WS1-TLB2 | LG Display | 10.1 | 1024×576 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
