| Nomor Bagian | G101EAN02.1 |
| Merek | AUO |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | AUO |
| ukuran diagonal | 10.1 inch |
| format piksel | 1280(RGB)×800 [WXGA] 149PPI |
| daerah aktif | 216.96(H)×135.6(V) mm |
| daerah bezel | - |
| pencahayaan | 400 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| warna pendukung | 16.7M 50% NTSC |
| berat | 195g (Max.) |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
| model | G101EAN02.1 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 227.72(H)×147.8(V) ×4.8(D) mm |
| perlakuan | Hard coating |
| rasio kontras | 800:1 (Typ.) (TM) |
| waktu merespon | 29 (Typ.)(Tr+Td) |
| Modus operasi | AHVA, Normally Black, Transmissive |
| sumber cahaya | WLED , 30K hours , With LED Driver |
| dirancang untuk | Industrial |
| panel sentuh | Without |
