| Nomor Bagian | G080UAN01.1 |
| Merek | AUO |
| Ukuran | 8.0 |
| Aplikasi | Industrial |
| Resolusi | 1200×1920 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | AUO |
| model panel | G080UAN01.1 |
| ukuran panel | 8.0" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1200(RGB)×1920, WUXGA, 283PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 107.64(W)×172.224(H) mm |
| bukaan bezel | - |
| kecerahan | - |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| mode tampilan | AHVA, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 27 (Typ.)(Tr+Tf) |
| menampilkan warna | 16.7M |
| jenis lampu | WLED , 15K hours , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Industrial |
| antarmuka sinyal | MIPI |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
