| Nomor Bagian | G057QTN01.4 |
| Merek | AUO |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | CMOS |
| merek panel | AUO |
| ukuran panel | 5.7" |
| resolusi | 320(RGB)×240, QVGA, 70PPI |
| area tampilan | 115.2(W)×86.4(H) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandang | 80/80/70/70 (Typ.)(CR≥10) |
| tampilan terbaik di | - |
| menampilkan warna | 262K |
| frekuensi | 60Hz |
| berat panel | - |
| antarmuka sinyal | CMOS (1 ch, 6-bit) |
| lingkungan | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C |
| model panel | G057QTN01.4 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| rasio kontras | 700:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 15/10 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 75K hours |
| layar sentuh | Without |
| aplikasi | Industrial |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| EL320.240.36 ET CC | Lumineq | 5.7 | 320×240 |
| G057QN01 V0 | AUO | 5.7 | 320×240 |
| G057QN01 V1 | AUO | 5.7 | 320×240 |
| G057QN01 V2 | AUO | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
