| Nomor Bagian | FX050720DSSWDG09 |
| Merek | Data Image |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 640×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| pabrikan | Data Image |
| nama model | FX050720DSSWDG09 |
| ukuran layar | 5.7 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 640(RGB)×480 (VGA) |
| pengaturan | RGB Vertical Stripe |
| sudut pandang | - |
| tanggapan | - |
| pemandangan bagus di | - |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K |
| lampu latar | WLED |
| massa | - |
| digunakan untuk | Industrial |
| jenis sinyal | Parallel RGB |
| AG-320240A4FIQW-K9H-S(N)(R) | AMPIRE | 5.7 | 320×240 |
| ER057005NC6 | EDT | 5.7 | 320×240 |
| G057VTN01.1 | AUO | 5.7 | 640×480 |
| KCS057QV1AJ-G39 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G000 | Kyocera | 5.7 | 320×240 |
| LM057QB1T09 | SHARP | 5.7 | 320×240 |
| M606-L24A | NAN YA | 5.7 | 320×240 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| SH320240C | Other | 5.7 | 320×240 |
| TM320240EGFWVSWD | Tianma | 5.7 | 320×240 |
