| Nomor Bagian | FDCC0802C-FLYYBH-91LE |
| Merek | Fordata |
| Ukuran | 1.1 |
| Aplikasi | Instruments & Me |
| Resolusi | 8×27 |
| Komposisi | STN-LCD, LCM |
| Kecerahan | |
| CR | 6:1 |
| Warna | Monochrome |
| Lampu latar | YG-LED |
| Antarmuka | 8-bit |
| merek panel | Fordata |
| model panel | FDCC0802C-FLYYBH-91LE |
| ukuran panel | 1.1" |
| tipe panel | STN-LCD, LCM |
| format tampilan | 8 characters × 2 lines, 7PPI |
| format huruf | 5×8 dots |
| ukuran karakter | 2.95×4.75(W×H) mm |
| nada karakter | 3.35×5.15(W×H) mm |
| area tampilan | 26.4(W)×9.9(H) mm |
| bukaan bezel | 30.4(W)×13.9(H) mm |
| ukuran garis besar | 40(W)×35.4(H) ×13(D) mm |
| permukaan | - |
| kecerahan | - |
| rasio kontras | 6:1 (Typ.) (TM) |
| sudut pandang | - |
| mode tampilan | STN, Yellow/Green (Positive), Transflective |
| tampilan terbaik di | 6 o'clock |
| waktu merespon | 150/150 (Typ.)(Tr/Td) |
| menampilkan warna | Monochrome |
| jenis lampu | YG-LED , 9K hours , Without Driver |
| frekuensi | - |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Instruments & Meters |
| antarmuka sinyal | 8-bit parallel , 16 pins Pad |
| tegangan masukan | 3.0V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
