| Nomor Bagian | FDCC0801A-NSWBBW-91LE |
| Merek | Fordata |
| Ukuran | 2.3 |
| Aplikasi | Instruments & Me |
| Resolusi | 5×8 |
| Komposisi | LCM, STN-LCD |
| Kecerahan | |
| CR | 6:1 |
| Warna | Monochrome |
| Lampu latar | WLED |
| Antarmuka | 8-bit |
| pabrikan | Fordata |
| nama model | FDCC0801A-NSWBBW-91LE |
| ukuran layar | 2.3 inch |
| tipe layar | LCM, STN-LCD |
| nomor karakter | 8 characters × 1 lines 3PPI |
| format char | 5×8 dots |
| nada arang (mm) | 7.15×10.75 (H×V) |
| ukuran arang (mm) | 6.45×10.75 (H×V) |
| area aktif (mm) | 56.5 × 10.75 (H×V) |
| garis besar (mm) | 84 × 44 × 13.5 (H×V×D) |
| area bezel (mm) | 61.0 × 15.8 (H×V) |
| perlakuan | - |
| pencahayaan | - |
| rasio kontras | 6 : 1 (Typ.) (TM) |
| sudut pandang | - |
| tanggapan | 150/150 (Typ.)(Tr/Tf) ms |
| pemandangan bagus di | 6 o'clock |
| mode kerja | STN, Blue mode (Negative), Transmissive |
| kedalaman warna | Monochrome |
| lampu latar | WLED , 9K hours , No Driver |
| massa | - |
| digunakan untuk | Instruments & Meters |
| tingkat penyegaran | - |
| layar sentuh | Without |
| jenis sinyal | 8-bit parallel , Pad 16 pins |
| sumber tegangan | 3.0V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
