| Nomor Bagian | F080A35-602 |
| Merek | Innolux |
| Ukuran | 8.0 |
| Aplikasi | Digital Photo Frame |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| merek panel | Innolux |
| ukuran panel | 8.0" |
| resolusi | 1024(RGB)×768, XGA, 160PPI |
| area tampilan | 162.048(W)×121.536(H) mm |
| ukuran garis besar | 171.124(W)×132.618(H) ×0.8(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| kedalaman kaca | 0.40+0.40 mm |
| menampilkan warna | 16.7M |
| frekuensi | - |
| ic pengemudi | COG Suggest NT39212C+NT51008 |
| berat panel | - |
| lingkungan | Operating Temp.: -10 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | F080A35-602 |
| tipe panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | - |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | AAS, Normally Black, Transmissive |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| keterusan | 4.0% (Typ.) |
| jenis lampu | No B/L |
| layar sentuh | Without |
| aplikasi | Digital Photo Frame |
