| Nomor Bagian | EMA-101201 |
| Merek | eMagin |
| Ukuran | 0.63 |
| Aplikasi | HMD VR AR |
| Resolusi | 1280×1024 |
| Komposisi | Si-OLED, OLED |
| Kecerahan | |
| CR | 1000:1 |
| Warna | Grayscale |
| Lampu latar | self |
| Antarmuka | LVDS |
| merek | eMagin |
| model | EMA-101201 |
| ukuran diagonal | 0.63 inch |
| jenis | Si-OLED, OLED |
| format piksel | 1280(LCR)×1024 [SXGA] 2619PPI |
| konfigurasi | LCR Vertical Stripe |
| daerah aktif | 12.4(H)×9.945(V) mm |
| garis besar redup. | 19.5(H)×14.8(V) ×5.4(D) mm |
| pencahayaan | 900 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | - |
| sudut pandang | - |
| Modus operasi | - |
| warna pendukung | Grayscale 52% NTSC |
| sumber cahaya | self |
| berat | 3.00g (Typ.) |
| dirancang untuk | HMD VR AR |
| kecepatan bingkai | - |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Sumber Daya listrik | 5/1.8/-1.5V (Typ.)(VDC/VDD/VPG) |
| lingkungan | Operating Temperature: -45 ~ 70 °C ; Storage Temperature: -55 ~ 90 °C |
| L3P06X-85G20 | Epson | 0.63 | 1024×768 |
