| Nomor Bagian | EL160.120.39-SPI |
| Merek | Lumineq |
| Ukuran | 3.1 |
| Aplikasi | Industrial |
| Resolusi | 160×120 |
| Komposisi | EL, EL |
| Kecerahan | |
| CR | 60:1 |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antarmuka | SPI |
| merek | Lumineq |
| model | EL160.120.39-SPI |
| ukuran diagonal | 3.1 inch |
| jenis | EL, EL |
| format piksel | 160×120 [QQVGA] 65PPI |
| konfigurasi | Rectangle |
| daerah aktif | 62.3(H)×46.7(V) mm |
| garis besar redup. | 93.6(H)×61.5(V) mm |
| pencahayaan | 70 cd/m² (Typ.) |
| rasio kontras | 60:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 1 (Max.) |
| sudut pandang | 89/89/89/89 (Typ.) |
| Modus operasi | - |
| warna pendukung | Mono(Yellow) |
| sumber cahaya | self , 50K hours |
| berat | 65.0g |
| dirancang untuk | Industrial |
| kecepatan bingkai | 150Hz |
| panel sentuh | Without |
| tipe antarmuka | SPI , 20 pins Connector |
| Sumber Daya listrik | 5.25/18V (Typ.)(VL/VH) |
| lingkungan | Operating Temperature: -50 ~ 70 °C ; Storage Temperature: -60 ~ 105 °C ; Vibration Level: 3.16G (31.0 m/s²) |
