| Nomor Bagian | DV490FBM-N00 |
| Merek | BOE |
| Ukuran | 48 |
| Aplikasi | Digital Signage Outd |
| Resolusi | 3840×720 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 1.07B |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | BOE |
| ukuran panel | 48" (Native bar) |
| resolusi | 3840(RGB)×720, 81PPI |
| area tampilan | 1194.05(W)×223.884(H) mm |
| ukuran garis besar | 1217.85(W)×247.68(H) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 1.07B 100% sRGB |
| frekuensi | 60Hz |
| berat | TBD |
| model panel | DV490FBM-N00 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Hard coating (3H) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | ADS, Normally Black, Transmissive |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| jenis lampu | WLED , Without Driver |
| layar sentuh | Without |
| aplikasi | Digital Signage Outdoor High Brightness Stretched Bar LCD |
