| Nomor Bagian | DV460FHM-NV2 |
| Merek | BOE |
| Ukuran | 46 |
| Aplikasi | Video Wall |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | BOE |
| ukuran layar | 46 inch |
| nomor piksel | 1920(RGB)×1080 (FHD) 47PPI |
| area aktif (mm) | 1018.08 × 572.67 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 500 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M 95% sRGB |
| jahitan penyambungan | 0.9 mm (active to active seam) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | LVDS (2 ch, 8-bit) , 51 pins Connector |
| sumber tegangan | 12.0V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | DV460FHM-NV2 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 1018.96 × 573.55 × 58.3 (H×V×D) |
| perlakuan | Antiglare (Haze 25%), Hard coating (2H) |
| rasio kontras | 1200 : 1 (Typ.) (TM) |
| tanggapan | 8 (Typ.)(G to G) ms |
| mode kerja | ADS, Normally Black, Transmissive |
| lampu latar | WLED , 50K hours , With LED Driver |
| digunakan untuk | Video Wall |
| layar sentuh | Without |
