| Nomor Bagian | DV430FHB-N10 |
| Merek | BOE |
| Ukuran | 43 |
| Aplikasi | Digital Signage |
| Resolusi | 1920×1080 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| pabrikan | BOE |
| ukuran layar | 43 inch |
| nomor piksel | 1920(RGB)×1080 (FHD) 51PPI |
| area aktif (mm) | 940.896 × 529.254 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 0 cd/m² |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| ketebalan kaca | 0.50+0.50 mm |
| kedalaman warna | 16.7M |
| massa | 1.51Kgs (Typ.) |
| tingkat penyegaran | 60Hz |
| daftar ic driver | Built-in COF 6 source chips |
| jenis sinyal | LVDS (2 ch, 8-bit) , 51 pins Connector |
| sumber tegangan | 12V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | DV430FHB-N10 |
| tipe layar | CELL , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 950.896 × 541.75 × 1.4 (H×V×D) |
| perlakuan | Antiglare (Haze 1%), Hard coating (3H) |
| rasio kontras | 1200 : 1 (Typ.) (TM) |
| tanggapan | 8 (Typ.)(G to G) ms |
| mode kerja | ADS, Normally Black, Transmissive |
| keterusan | 6.3% (Typ.)(with Polarizer) |
| lampu latar | No B/L |
| digunakan untuk | Digital Signage |
| layar sentuh | Without |
