| Nomor Bagian | DV363FBB-N00 |
| Merek | BOE |
| Ukuran | 36.3 |
| Aplikasi | Digital Signage |
| Resolusi | 1216×2160 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| merek panel | BOE |
| model panel | DV363FBB-N00 |
| ukuran panel | 36.3" |
| tipe panel | a-Si TFT-LCD, CELL |
| resolusi | 1216(RGB)×2160, 68PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 452.352(W)×803.52(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 464.352(W)×809.62(H) mm |
| permukaan | Antiglare (Haze 1%) |
| kecerahan | 0 cd/m² |
| rasio kontras | 1200:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 8 (Typ.)(G to G) |
| kedalaman kaca | 0.50+0.50 mm |
| keterusan | 5.1% (Typ.)(with Polarizer) |
| menampilkan warna | 16.7M 72% NTSC |
| jenis lampu | No B/L |
| frekuensi | 60Hz |
| layar sentuh | Without |
| ic pengemudi | COGBuilt-in 4 source chips |
| berat panel | 1.20Kgs (Typ.) |
| aplikasi | Digital Signage |
| antarmuka sinyal | LVDS (2 ch, 8-bit) , 51 pins Connector |
| tegangan masukan | 12.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
