| Nomor Bagian | DMF50260NFU-FW-27 |
| Merek | OPTREX |
| Ukuran | 9.4 |
| Aplikasi | Industrial |
| Resolusi | 640×480 |
| Komposisi | FSTN-LCD , LCM |
| Kecerahan | |
| CR | 14:1 |
| Warna | Monochrome |
| Lampu latar | - |
| Antarmuka | |
| merek panel | OPTREX |
| ukuran panel | 9.4" |
| resolusi | 640×480, VGA, 84PPI |
| area tampilan | 191.97(W)×143.97(H) mm |
| kecerahan | - |
| sudut pandang | - |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | Monochrome |
| frekuensi | 70Hz |
| berat | - |
| model panel | DMF50260NFU-FW-27 |
| tipe panel | FSTN-LCD , LCM |
| format piksel | Rectangle |
| bukaan bezel | - |
| rasio kontras | 14:1 (Typ.) (TM) |
| mode tampilan | STN, Black/White mode, Transmissive |
| waktu merespon | 210/120 (Typ.)(Tr/Td) |
| jenis lampu | |
| layar sentuh | Without |
| aplikasi | Industrial |
| AV094Z9M-N10 | BOE | 9.4 | 1920×480 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| LJ640U48 | SHARP | 9.4 | 640×480 |
| LM64183P | SHARP | 9.4 | 640×480 |
| LM64P81 | SHARP | 9.4 | 640×480 |
| LP094WX1-SLA2 | LG Display | 9.4 | 1280×800 |
| LTM09C015A | TOSHIBA | 9.4 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| SP24V001 | KOE | 9.4 | 640×480 |
