| Nomor Bagian | DMF-50174 |
| Merek | OPTREX |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | STN-LCD, LCM |
| Kecerahan | |
| CR | |
| Warna | Monochrome |
| Lampu latar | CCFL |
| Antarmuka | Parallel |
| merek | OPTREX |
| model | DMF-50174 |
| ukuran diagonal | 5.7 inch |
| jenis | STN-LCD, LCM |
| format piksel | 320×240 [QVGA] 70PPI |
| konfigurasi | Rectangle |
| daerah aktif | 115.17(H)×86.37(V) mm |
| garis besar redup. | 174(H)×112(V) ×14(D) mm |
| daerah bezel | 122.0(H)×92.0(V) mm |
| perlakuan | - |
| arah pandangan | - |
| waktu merespon | - |
| sudut pandang | - |
| Modus operasi | STN |
| warna pendukung | Monochrome |
| sumber cahaya | CCFL , W/O Driver |
| berat | - |
| dirancang untuk | Industrial |
| kecepatan bingkai | 70Hz |
| panel sentuh | Without |
| tipe antarmuka | Parallel Data (1ch, 4-bit) , 14 pins Connector |
| Sumber Daya listrik | 5.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
