| Nomor Bagian | CT024TN02 V.9 |
| Merek | Innolux |
| Ukuran | 2.4 |
| Aplikasi | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 300:1 |
| Warna | 65K |
| Lampu latar | WLED |
| Antarmuka | |
| merek | Innolux |
| model | CT024TN02 V.9 |
| ukuran diagonal | 2.4 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 240(RGB)×320 [QVGA] 166PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 36.72(H)×48.96(V) mm |
| garis besar redup. | - |
| pencahayaan | - |
| rasio kontras | 300:1 (Typ.) (TM) |
| arah pandangan | 12 o'clock |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| sudut pandang | 45/45/50/20 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 65K 60% NTSC |
| sumber cahaya | WLED |
| berat | - |
| dirancang untuk | Mobile Phone |
| kecepatan bingkai | - |
| panel sentuh | 4-wire Resistive Touch |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
