| Nomor Bagian | CM546B2-001 |
| Merek | CSOT |
| Ukuran | 5.5 |
| Aplikasi | Mobile Phone |
| Resolusi | 1080×1920 |
| Komposisi | LTPS TFT-LCD, CELL |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| merek panel | CSOT |
| model panel | CM546B2-001 |
| ukuran panel | 5.5" |
| tipe panel | LTPS TFT-LCD, CELL |
| resolusi | 1080(RGB)×1920, FHD, 403PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 68.04(W)×120.96(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 69.44(W)×126.81(H) ×0.45(D) mm |
| permukaan | With Polarizer |
| kecerahan | 0 cd/m² |
| rasio kontras | 1500:1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| mode tampilan | FFS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 35 (Typ.)(Tr+Td) |
| kedalaman kaca | 0.15+0.15 mm |
| keterusan | 4.69% (Typ.)(with APCF) |
| menampilkan warna | 16.7M 80% NTSC |
| jenis lampu | No B/L |
| frekuensi | - |
| layar sentuh | In-Cell Touch |
| ic pengemudi | COG Built-in TD4310 |
| berat panel | TBD |
| aplikasi | Mobile Phone |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| E555HBM2 | EDO | 5.5 | 720×1280 |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| TM055JDHP71 | Tianma | 5.5 | 720×1280 |
