| Nomor Bagian | CLAA123PA02CW |
| Merek | CPT |
| Ukuran | 12.3 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1440×540 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | CPT |
| model | CLAA123PA02CW |
| ukuran diagonal | 12.3 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1440(RGB)×540 125PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 291.6(H)×109.35(V) mm |
| garis besar redup. | 312.9(H)×132.2(V) ×19.2(D) mm |
| daerah bezel | 294.8(H)×112.4(V) mm |
| perlakuan | Antiglare (Haze 25%) |
| pencahayaan | 800 cd/m² (Typ.) |
| rasio kontras | 700:1 (Typ.) (TM) |
| arah pandangan | 6 o'clock |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 60/60/50/60 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 16.7M 70% NTSC |
| sumber cahaya | WLED [8S3P] , 30K hours , W/O Driver |
| berat | 510g (Typ.) |
| dirancang untuk | Industrial Outdoor High Brightness Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
