| Nomor Bagian | CLAA101WK07 XN |
| Merek | CPT |
| Ukuran | 10.1 |
| Aplikasi | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | CPT |
| ukuran diagonal | 10.1 inch |
| format piksel | 1280(RGB)×720 [WXGA] 144PPI |
| daerah aktif | 224.64(H)×126.36(V) mm |
| daerah bezel | 227.64(H)×129.36(V) mm |
| pencahayaan | 600 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| warna pendukung | 262K/16.7M 70% NTSC |
| berat | 430g (Typ.) |
| kecepatan bingkai | 60Hz |
| model | CLAA101WK07 XN |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 238.8(H)×148.05(V) ×8.7(D) mm |
| perlakuan | Antiglare (Haze 25%), Hard coating (3H) |
| rasio kontras | 900:1 (Typ.) (TM) |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| Modus operasi | HFFS, Normally Black, Transmissive |
| sumber cahaya | WLED [6S5P] , 30K hours , W/O Driver |
| dirancang untuk | Automotive Display |
| panel sentuh | Without |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
