| Nomor Bagian | CLAA080WK02 XN |
| Merek | CPT |
| Ukuran | 8.0 |
| Aplikasi | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | CPT |
| model | CLAA080WK02 XN |
| ukuran diagonal | 8.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×720 [WXGA] 183PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 177.024(H)×99.576(V) mm |
| garis besar redup. | 186.5(H)×117.22(V) ×13.1(D) mm |
| daerah bezel | 179.03(H)×101.58(V) mm |
| perlakuan | Antiglare (Haze 25%) |
| pencahayaan | 600 cd/m² (Typ.) |
| rasio kontras | 900:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | HFFS, Normally Black, Transmissive |
| warna pendukung | 262K/16.7M 70% NTSC |
| sumber cahaya | WLED [5S4P] , 30K hours , W/O Driver |
| berat | TBD |
| dirancang untuk | Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| Sumber Daya listrik | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| lingkungan | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
