| Nomor Bagian | CLAA070WP03XG |
| Merek | CPT |
| Ukuran | 7.0 |
| Aplikasi | PAD |
| Resolusi | 800×1280 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | CPT |
| model panel | CLAA070WP03XG |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800(RGB)×1280 , WXGA |
| mode tampilan | HFFS, Normally Black, Transmissive |
| daerah aktif | 94.2×150.72 mm |
| garis besar | 104.32×161.67×4.05 mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| rasio kontras | 700:1 (Typ.) |
| menampilkan warna | 262K (6-bit), CIE193160% |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | LVDS (1 ch, 6-bit), 31 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
