| Nomor Bagian | CLAA061LA0NCW |
| Merek | CPT |
| Ukuran | 6.1 |
| Aplikasi | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek | CPT |
| ukuran diagonal | 6.1 inch |
| format piksel | 800(RGB)×480 [WVGA] 153PPI |
| daerah aktif | 136.2(H)×72(V) mm |
| pencahayaan | - |
| arah pandangan | 6 o'clock |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| warna pendukung | 262K 70% NTSC |
| berat | - |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | TTL (1 ch, 6-bit) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model | CLAA061LA0NCW |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | - |
| rasio kontras | 400:1 (Typ.) (TM) |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| Modus operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED , 30K hours |
| dirancang untuk | Automotive Display |
| panel sentuh | Without |
