| Nomor Bagian | CLAA042JD02 XN |
| Merek | CPT |
| Ukuran | 4.2 |
| Aplikasi | Automotive Display |
| Resolusi | 480×272 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| pabrikan | CPT |
| ukuran layar | 4.2 inch |
| nomor piksel | 480(RGB)×272 (WQVGA) 131PPI |
| area aktif (mm) | 92.88 × 52.632 (H×V) |
| area bezel (mm) | 94.48 × 54.27 (H×V) |
| pencahayaan | 700 (Typ.)(cd/m²) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 262K |
| massa | 97.4g (Max.) |
| tingkat penyegaran | 60Hz |
| nama model | CLAA042JD02 XN |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 102.5 × 67 × 11.3 (H×V×D) |
| perlakuan | Antiglare |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| mode kerja | HFFS, Normally Black, Transmissive |
| tanggapan | 25 (Max.)(Tr+Td) ms |
| lampu latar | WLED , 50K hours , No Driver |
| digunakan untuk | Automotive Display |
| layar sentuh | Without |
