| Nomor Bagian | C123VAN01.0 |
| Merek | AUO |
| Ukuran | 12.3 |
| Aplikasi | Automotive Display |
| Resolusi | 1440×540 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | |
| Warna | 16.7M |
| Lampu latar | - |
| Antarmuka | RSDS |
| merek panel | AUO |
| ukuran panel | 12.3" |
| resolusi | 1440(RGB)×540, 125PPI |
| area tampilan | 291.6(W)×109.35(H) mm |
| ukuran garis besar | 308.5(W)×129(H) mm |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M |
| frekuensi | 60Hz |
| berat panel | 580±58g |
| antarmuka sinyal | RSDS (1 Channel) FPC |
| lingkungan | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
| model panel | C123VAN01.0 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 294.8(W)×112.35(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| mode tampilan | AHVA, Normally Black, Transmissive |
| waktu merespon | - |
| jenis lampu | |
| layar sentuh | Without |
| aplikasi | Automotive Display |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
