| Nomor Bagian | C084XAN01.0 |
| Merek | AUO |
| Ukuran | 8.4 |
| Aplikasi | Automotive Display |
| Resolusi | 1024×768 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | AUO |
| ukuran layar | 8.4 inch |
| nomor piksel | 1024(RGB)×768 (XGA) 152PPI |
| area aktif (mm) | 170.496 × 127.872 (H×V) |
| pencahayaan | - |
| sudut pandang | - |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M |
| massa | - |
| tingkat penyegaran | 60Hz |
| jenis sinyal | LVDS (1 ch, 8-bit) , 40 pins Connector |
| maks. peringkat | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| nama model | C084XAN01.0 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | - |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| tanggapan | 30 (Max.)(Tr+Td) ms |
| mode kerja | AHVA, Normally Black, Transmissive |
| lampu latar | WLED |
| digunakan untuk | Automotive Display |
| layar sentuh | Without |
