| Nomor Bagian | C080EAN04.1 |
| Merek | AUO |
| Ukuran | 8.0 |
| Aplikasi | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 6S4P |
| Antarmuka | |
| pabrikan | AUO |
| nama model | C080EAN04.1 |
| ukuran layar | 8.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1280(RGB)×720 (WXGA) 184PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 176.64 × 99.36 (H×V) |
| garis besar (mm) | 186.5 × 117.12 (H×V×D) |
| area bezel (mm) | 179.55 × 105.36 (H×V) |
| perlakuan | Antiglare |
| pencahayaan | 750 cd/m² (Typ.) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tanggapan | 20 (Max.)(Tr+Tf) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | AHVA, Normally Black, Transmissive |
| kedalaman warna | 16.7M 68% NTSC |
| lampu latar | 6S4P WLED , 30K hours , No Driver |
| massa | 229±23g |
| digunakan untuk | Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
