| Nomor Bagian | BV050HDE-NBA-3Q00 |
| Merek | BOE |
| Ukuran | 5.0 |
| Aplikasi | Mobile Phone |
| Resolusi | 720×1280 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| merek panel | BOE |
| model panel | BV050HDE-NBA-3Q00 |
| ukuran panel | 5.0" |
| tipe panel | a-Si TFT-LCD, CELL |
| resolusi | 720(RGB)×1280, WXGA, 294PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 62.1(W)×110.4(H) mm |
| bukaan bezel | - |
| kecerahan | 0 cd/m² |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 70% NTSC |
| jenis lampu | No B/L |
| frekuensi | - |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Mobile Phone |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
