| Nomor Bagian | BA104S01-400 |
| Merek | BOE |
| Ukuran | 10.4 |
| Aplikasi | Digital Photo Frame |
| Resolusi | 800×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | 3S12P |
| Antarmuka | Parallel |
| merek panel | BOE |
| ukuran panel | 10.4" |
| resolusi | 800(RGB)×600, SVGA, 96PPI |
| area tampilan | 211.2(W)×158.4(H) mm |
| ukuran garis besar | 228.4(W)×175.4(H) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandang | 80/80/65/75 (Typ.)(CR≥10) |
| tampilan terbaik di | - |
| menampilkan warna | 262K/16.7M 55% NTSC |
| frekuensi | 60Hz |
| berat panel | TBD |
| antarmuka sinyal | Parallel RGB (1 ch, 6/8-bit) , 60 pins FPC |
| tegangan masukan | 3.3/9/18/-8V (Typ.)(VCC/AVDD/VGH/VGL) |
| lingkungan | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| model panel | BA104S01-400 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 214.4(W)×161.6(H) mm |
| permukaan | Antiglare |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| jenis lampu | 3S12P WLED , 20K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Digital Photo Frame Home Appliance |
