| Nomor Bagian | B156XTN07.0 HWKA |
| Merek | AUO |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | AUO |
| model panel | B156XTN07.0 HWKA |
| ukuran panel | 15.6" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 100PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 344.232(W)×193.536(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 359.5(W)×223.8(H) mm |
| permukaan | - |
| kecerahan | - |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | 45/45/15/35 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | 6 o'clock |
| waktu merespon | 8 (Typ.)(Tr+Td) |
| menampilkan warna | 262K |
| jenis lampu | WLED |
| frekuensi | - |
| layar sentuh | Without |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (1 Lane) , 30 pins Connector |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B156XTN02.0 | AUO | 15.6 | 1366×768 |
| B156XTN02.2 | AUO | 15.6 | 1366×768 |
| B156XTN02.4 | AUO | 15.6 | 1366×768 |
| B156XTN03.1 | AUO | 15.6 | 1366×768 |
| B156XTN03.2 | AUO | 15.6 | 1366×768 |
| B156XTN03.5 | AUO | 15.6 | 1366×768 |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| B156XTN04.5 | AUO | 15.6 | 1366×768 |
| B156XTN05.0 | AUO | 15.6 | 1366×768 |
| LQ156D1JX03 | SHARP | 15.6 | 3840×2160 |
