AUO B141EW01 V3 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


B141EW01 V3

B141EW01 V3
B141EW01 V3
B141EW01 V3
B141EW01 V3 thumb B141EW01 V3 thumb B141EW01 V3 thumb
Merek
AUO
Ukuran
14.1
Aplikasi
NBPC
Resolusi
1280×800
Komposisi
LCM
Kecerahan
200
CR
350:1
Warna
262K
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
14724
Spesifikasi

Nomor Bagian B141EW01 V3
MerekAUO
Ukuran14.1
AplikasiNBPC
Resolusi1280×800
KomposisiLCM
Kecerahan200
CR350:1
Warna262K
Lampu latarCCFL
AntarmukaLVDS
merek panelAUO
model panelB141EW01 V3 1 Compatible model
tipe panel a-Si TFT-LCD , LCM
ukuran panel14.1 inch
resolusi1280(RGB)×800 , WXGA
mode tampilanTN, Normally White, Transmissive
daerah aktif303.36×189.6 mm
garis besar319.5×205.5×5.5 mm
gaya bentukWedge (PCBA Bent, Depth ≥5.2mm)
permukaanGlare (Haze 0%)
kecerahan200 cd/m² (Typ.)
rasio kontras350:1 (Typ.)
menampilkan warna262K (6-bit)
waktu merespon15/10 (Typ.)(Tr/Td)
sudut pandang45/45/20/35 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu1 pcsCCFLWithout Driver
antarmuka sinyalLVDS (1 ch, 6-bit), 30 pins
tegangan masukan3.3V (Typ.)
aplikasiNBPC
