| Nomor Bagian | B140XTK02.1 |
| Merek | AUO |
| Ukuran | 14.0 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | AUO |
| model panel | B140XTK02.1 (AUO213C) |
| ukuran panel | 14.0" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 112PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 309.399(W)×173.952(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 315.9(W)×197.54(H) ×3.2(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 200 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) (TM) |
| sudut pandang | 45/45/15/35 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | 6 o'clock |
| waktu merespon | 8 (Typ.)(G to G) |
| menampilkan warna | 262K 44% NTSC |
| jenis lampu | WLED , 15K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | On-Cell Touch |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (1 Lane) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
