| Nomor Bagian | B125XTN01.0 HW1A |
| Merek | AUO |
| Ukuran | 12.5 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | AUO |
| model panel | B125XTN01.0 HW1A (AUO106C) |
| ukuran panel | 12.5" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 125PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 276.615(W)×155.52(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 300.4(W)×181.4(H) ×3(D) mm |
| permukaan | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| kecerahan | 200 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) (TM) |
| sudut pandang | 45/45/15/35 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | 6 o'clock |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 45% NTSC |
| jenis lampu | WLED , 15K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B125HAN01.0 | AUO | 12.5 | 1920×1080 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| HB125WX1-200 | BOE | 12.5 | 1366×768 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB2 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| M125NWR3 R0 | IVO | 12.5 | 1366×768 |
| NV125QUM-N81 | BOE | 12.5 | 3840×2160 |
