| Nomor Bagian | B116XAK01.2 |
| Merek | AUO |
| Ukuran | 11.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | eDP |
| pabrikan | AUO |
| ukuran layar | 11.6 inch |
| nomor piksel | 1366(RGB)×768 (WXGA) 135PPI |
| area aktif (mm) | 256.125 × 144 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 235 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 262K 50% NTSC |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | eDP (1 Lane) , eDP1.2 , 40 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C |
| nama model | B116XAK01.2 (AUO125C) |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 278 × 168.02 × 3.2 (H×V×D) |
| perlakuan | Antiglare, Hard coating (3H) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| tanggapan | 27 (Typ.)(Tr+Tf) ms |
| mode kerja | AHVA, Normally Black, Transmissive |
| lampu latar | WLED , 15K hours , With LED Driver |
| digunakan untuk | Laptop |
| layar sentuh | On-Cell Touch |
