| Nomor Bagian | B116XAK01.0 |
| Merek | AUO |
| Ukuran | 11.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| merek | AUO |
| model | B116XAK01.0 (AUO405C) |
| ukuran diagonal | 11.6 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1366(RGB)×768 [WXGA] 135PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 256.125(H)×144(V) mm |
| garis besar redup. | 278(H)×168.02(V) ×3.2(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 250 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 27 (Typ.)(Tr+Tf) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | AHVA, Normally Black, Transmissive |
| warna pendukung | 262K 50% NTSC |
| sumber cahaya | WLED , 15K hours , With LED Driver |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| dirancang untuk | Laptop |
| kecepatan bingkai | 60Hz |
| panel sentuh | On-Cell Touch |
| Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
