| Nomor Bagian | B080UAN01.4 |
| Merek | AUO |
| Ukuran | 8.0 |
| Aplikasi | PAD |
| Resolusi | 1200×1920 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | AUO |
| model panel | B080UAN01.4 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 8.0 inch |
| resolusi | 1200(RGB)×1920 , WUXGA |
| mode tampilan | AHVA, Normally Black, Transmissive |
| daerah aktif | 107.64×172.224 mm |
| garis besar | 114.6×184.6×3.65 mm |
| permukaan | Hard coating (1H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193160% |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 7S3PWLEDWithout Driver |
| antarmuka sinyal | MIPI (4 data lanes), 45 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
