| Nomor Bagian | AX080E002B |
| Merek | KOE |
| Ukuran | 31.5 |
| Aplikasi | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 950:1 |
| Warna | 16.7M |
| Lampu latar | EEFL |
| Antarmuka | LVDS |
| merek panel | IPS Alpha |
| model panel | AX080E002B |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 31.5 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mode tampilan | IPS-Pro, Normally Black, Transmissive |
| daerah aktif | 697.685×392.256 mm |
| garis besar | 760×450 mm |
| permukaan | Antiglare |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 950:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit) |
| waktu merespon | 8/6 (Typ.)(Tr/Td); 17 (Typ.)(MPRT) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 16 pcsEEFLEmbedded (Inverter) |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 41 pins |
| tegangan masukan | 12.0V (Typ.) |
| aplikasi | LCTV |
